| Model | ZS195 | ZS1100 | ZS1105 | ZS1110 | ZS1115 |
| type | Single cylinder, horizontal, 4-stroke, water-cooled | ||||
| Combustion system | Direct injection | ||||
| Bore *stroke(mm) | 95*115 | 100*115 | 105*115 | 110*115 | 115*115 |
| Total displacement(L) | 0.815 | 0.903 | 0.996 | 1.093 | 1.194 |
| Rated power(kw.rpm) | 8.82 | 11.03 | 12.1 | 13.24 | 14.7 |
| Max power (kw.rpm) | 9.7 | 12.13 | 13.31 | 14.56 | 16.17 |
| Rated speed(r/min) | 2000 | 2200 | 2200 | 2200 | 2200 |
| Specific fuel | ≤244.8 | ≤246.2 | ≤246.2 | ≤244.8 | ≤244.8 |
| (g/kw.h) | |||||
| Cooling system | condensing | ||||
| Lubrication Method | Spray Pressure splash | ||||
| Start method | Hand start / electric start | ||||
| Net weight | 150 | 155 | 160 | 180 | 180 |
