Item | Parameter |
Model | LY500 |
Structure | Front-mounted |
Engine Model | 170F Gasoline engine |
Rated Power | 4.1 KW |
Dimension(L*W*H) | 1450*600*650MM |
Weight | 74KG |
Connection Model | Triangle Belt |
Connection mode | Direct Connection |
Horizontal | 180°/360° |
Adjustmentrange Of handlebar Vertical | 120° |
Rotate Speed | I gear 101 r/min ; II gear 133r/min |
Max Turning Radius | 165mm |
Kinfe Roll Number of Blades | 24/32 |
Model of rotary blade | 165mm |
Main clutch type | Tensioner |
Tilling width | 700mm |
Tillling depth | ≥100mm |
Operation Speed | ≥0.3m/s |
Productivity | 0.1-0.2h㎡（h.m) |
Fuel Consumption | ≤10kg/h㎡ |
Wheel Size | 400-8.400-10/350-6 |
Yantai blue speed mechanical and electrical equipment co., LTD. Is committed to the production and sales of mini power tiller tractor service international customers in more than 20 countries. To provide you with quality mini power tiller tractor, Yantai blue speed mechanical and electrical equipment Co., Ltd. set production, research and development, sales in one.
