| Specification | |||
| Mini Tillers | Dimension(L*W*H) | 1800×1050×850 | 1800×1350×900 |
| Max tilling scope(mm) | 800～1100 | 800～1300 | |
| Tilling depth | 150～300 | 150～300 | |
| Gear shifting | 0,1,2,-1 | 0,1,2,-1 | |
| Main running-in method | Machine grind-in | Machine grind-in | |
| Gear distance(mm) | 500 | 500 | |
| Productivity(mu/h) | 0.8～1.5 | 0.8～1.8 | |
| Engine | Engine model | 178FA | 188FAE |
| Engine type | Single-cylinder, vertical, air-cooling, 4-stroke, direct injection | ||
| Bore×stroke | 78×62 | 88×72 | |
| Displacement(L) | 0.296 | 0.438 | |
| Rated Power(max)kw(hp)/rpm | 4.4(7.0)/3600 | 6.7(14)/3600 | |
| Starting system | Recoil start | ||
| Fuel tank capacity(L) | 3.5 | 5.5 | |
| Fuel number | Num.0(summer) | Num.-10(winter) | |
| Lube capacity(L) | 1.1 | ||
| Suitable lube | SAE10W, above CCgrade | ||
| Lube mode | Pressure splash mode | ||
| Net weight | ≤33 | ≤52 | |
| Dimension(L×W×H)mm | 383×421×450 | 420×450×495 | |
