| 项目Item | 参数Parameter |
| 规格型号Model | LY500 |
| 结构形式Structure | 前置式Front-mounted |
| 发动机型号Engine Model | 170F汽油机Gasoline engine |
| 额定功率Rated Power | 4.1 KW |
| 外型尺寸（长*宽*高）Dimension(L*W*H) | 1450*600*650MM |
| 结构质量 Weight | 74KG |
| 转动方式Connection Model | 三角带传动Triangle Belt |
| 连接方式Connection mode | 直联式Direct Connection |
| 扶把调整幅度 水平方向Horizontal | 180°/360° |
| Adjustmentrange Of handlebar Vertical 垂直方向 | 120° |
| 转速Rotate Speed | I 档gear 101 r/min ; II 档gear 133r/min |
| 刀辊 最大回转半径Max Turning Radius | 165mm |
| Kinfe Roll 总安装刀数 Number of Blades | 24/32 |
| 旋耕刀型号Model of rotary blade | 165mm |
| 主离合器形式Main clutch type | 涨紧轮式Tensioner |
| 耕宽Tilling width | 700mm |
| 耕深 Tillling depth | ≥100mm |
| 作业速度Operation Speed | ≥0.3m/s |
| 作业小时生产率 Productivity | 0.1-0.2h㎡（h.m) |
| 单位作业面积燃油消耗量Fuel Consumption | ≤10kg/h㎡ |
| 轮胎尺寸Wheel Size | 400-8.400-10/350-6 |
