| Model | 2BYF-2 | 2BYF-3 | 2BYF-4 | 2BYF-5 | 2BYF-6 |
| Overall dimension (mm) | 1300*1620*1000 | 1700*1620*1100 | 2800*1620*1100 | 3000*1620*1100 | 3750*1620*1100 |
|
Row spacing (mm) |
500-700Adjustable | ||||
| Matched power (hp) | 12 | 24-50 | 24-50 | 24-80 | 24-80 |
| Fertilizer depth (mm) | 30-70 Adjustable | ||||
| Fertilizer colter booth | furrow colter boot | ||||
| Seed colter boot | moldboard colter boot | ||||
| Seeding depth (mm) | 30-50 Adjustable | ||||
| Furrow cover | disc furrow cover | ||||
| Linkage | Mounted three-point linkage | ||||
| Type of drive | land wheel-transmission | ||||
| Working speed (km/h) | 5-7 | ||||
| Kinds of sowing | Maize; soybean | ||||
| Weight (kg) | 110 | 160 | 200 | 250 | 300 |
| QTY LODE OF THE CONTAINER | 20' / 70sets | 20' / 60sets | 20' / 40 sets | 20' / 30 sets | 20' / 20 sets |
| 40' / 150sets | 40' / 130sets | 40' / 90 sets | 40' / 70 sets | 40' / 50 sets |
