LSEC-30-60HP Compact Tractor (2) It is used for cultivation and management of orchards, tea gardens, vineyards, mountains, hills and sun sheds. Such as rotary tillage, fertilization, soil cultivation, spraying and other operations, the wheelbase is narrow, generally between 0.85-1m, and the wheelbase is short between 1.4-1.6m. It has good steering performance and many machine tool interfaces. . Orchard and sun shed tires are small in diameter, low in height and compact, and the filter and muffler are arranged in the lower row, which has good space passability.
| Model | 304/ 404 /504 / 604 |
| Engine brand | LAIDONG /YTO |
| Engine type | 3 cylinders/4 cylinders, direct injection, naturally aspirated |
| Power (HP) | 30/ 40/ 50/ 60 |
| Fuel tank capacity(L) | 37 sideways |
| Gearbox | 8+2/8+8 |
| Front Wheel Center（mm） | 1250 |
| Front wheel full outside(mm) | 1420 |
| Rear Wheel Center (mm) | 1260 |
| Rear wheel full outside (mm) | 1500 |
| Ground clearance | 250 |
| Dimensions (mm) | 2530x1560x1560 |
| PTO speed | 540/720 |
| Steering Type | hydraulic steering |
| Clutch form | single acting/double acting |
| Suspension type | three point suspension |
| Cab | Awning or anti-roll frame |
| Optional tires | 6.00-12/ 9.50-16 |
