No. |
Specification |
LSE-50HP |
|
1 |
Engine |
Stage II diesel engine with direct injection |
|
2 |
Engine Power |
50HP |
|
3 |
Braking System |
Cylindrical, mechanically operated; acting on rear wheels simultaneously and independently. Same system applies for parking brakes |
|
4 |
Number of Gears |
8F+2R |
|
5 |
Steering |
Mechanical |
|
6 |
Number of Cylinders |
4 cylinders |
|
7 |
Cylinder Bore |
95mm |
|
8 |
Piston Stroke |
127mm |
|
9 |
Clutch Housing |
Dual-stage clutch |
|
10 |
Engine Displacement |
2.9L |
|
11 |
Air Filter |
Oil bath type |
|
12 |
Cooling System |
Pressurized water cooling |
|
13 |
Battery |
12V,75 Ah |
|
14 |
Alternator |
36A |
|
15 |
Hydraulic System |
16L/min |
|
16 |
Ignition |
Key start with safety switch |
|
17 |
Wheels and Tires |
Front: 600-16 / 8PR; Rear: 12.4-28 / 8PR |
|
18 |
Lighting |
2 main headlights, 2 rear position lights, 2 front flashing lights |
|
19 |
Cooling System Capacity |
10L |
|
20 |
Length |
3000 mm |
|
21 |
Height |
2000 mm (maximum exhaust height) |
|
22 |
Wheelbase |
1800mm |
|
23 |
Ground Clearance |
350 |
|
24 |
Weight |
1650 |
|
25 |
Fuel Tank Capacity |
40L |
|
26 |
Cooling System Capacity |
10L |
|
27 |
Standard Equipment |
Air compressor; Hand throttle; Parking brake lever; Drawbar; Toolbox; Suspended seat with spring; Tachometer (RPM meter); Oil pressure gauge; Temperature gauge; Ignition indicator; Main lights indicator; Oil filter restriction indicator |
