Type 12 excavator（side swing）
- Main Features
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution.
5) Apply a linker to connect with the air conveyor, which can directly inline with filling machine.
| Weight(KG) | 900 |
| Engine | Popular Science/Changchai |
| Rated power(KW) | 8.6 |
| Work pressure(Mpa) | 16 |
| Crutch | 55° left and right |
| Walking speed(KM/h) | 2.2 |
| Swing speed(r/min) | 13 |
| Bucket capacity(m³) | 0.025 |
| Fuel tank volume(L) | 10.2 |
| Gradeability(°) | 30 |
| Ground pressure（kpa） | 20 |
| Stick digging force（KN） | 4.6 |
| Bucket Digging Force（KN） | 7.2 |
| Main dimensions（mm） | |
| Total length | 2876 |
| Total width | 850 |
| Stretch width | 950 |
| Shrink width | 800 |
| Overall height (seat) | 1610 |
| Overall height (carport) | 2200 |
| Counterweight Ground Clearance | 385 |
| Minimum ground clearance | 132 |
| Tail turning radius | 800 |
| Track ground length | 900 |
| Track length | 1233 |
| Gauge | 670 |
| Track width | 840 |
| Track shoe width | 180 |
| Working range | |
| Maximum excavation height | 2550 |
| Maximum unloading height | 1687 |
| Maximum excavation depth | 1787 |
| Maximum vertical arm digging depth | 1626 |
| Maximum digging distance | 3077 |
| Maximum excavation distance at ground level | 2992 |
