MODEL | 504 |
Horsepower&Drive Type | 50hp, 4×4 |
ENGINE | |
Engine Model | 50HP |
Type | Vertical, Water-Cooled, Four Strokes, Direct in Injection |
Rated Output(kW) | 36.8 |
TRACTOR PARAMETER | |
Dimension L*W*H (mm) | 3558*1500*2245 |
Wheel Base (mm) | 1900 |
Wheel Tread F/R(mm) | 1060/1100 |
Min Ground Clearance(mm) | 300 |
TRANSMISSION | |
Gear Shift | 8F+2R |
Clutch Type | Dry Single-stage |
RUNNING SYSTEM | |
Tire F/R | 650-16/11.2-24 |
Steering | Hydraulic Steering |
Brake | Toe Type |
Park Brake | Latch Pedal |
WORKING SYSTEM | |
Hitch | Partial Separated Type, 3-Point hydraulic hitch，CategoryⅠ |
Max. Lift Force(N) | ≥6300 |
Rear PTO | Rear Rectangle Spline, 6 Teeth, 540/720rpm |
804 new agriculture 4WD farm tracker, matching with engines made in China, has strong power, large torque reserve and can meet the needs of different users;
Power emission upgrade, performance upgrade, low fuel consumption, high reliability, more advanced technology
804 new agriculture 4WD farm tracker adopts 16F + 8R synchronizer shuttle shift gearbox with full helical gear transmission, which makes the operation more flexible and light;
804 new agriculture 4WD farm tracker is equipped with imported German original Luk clutch, which is more flexible and reliable;
The front drive adopts universal joint drive shaft, which has large torque transmission and high reliability.
